Water Metering Devices

WP20

NB-IoT Smart Water Meter

WX800 Series

Designed for residential use, WP20 NB-IoT smart meter is the latest offering for water utilities to complement EDMI’s electricity and gas metering product lines.

Product Available In:

  • Africa & Middle East
  • Asia
  • Australasia
  • Europe

Key Features

Standards and Compliance

  • NMI R-49
  • AS/NZS 2845.1
  • AS 3565
  • AS 2345
  • AS/NZS 4020
  • AS 1722.2 Class B
  • Telstra Certification
  • RCM

Key Specifications

Nominal Diameter
  • DN20
Metrology
  • Technology: Ultrasonic, optional pressure sensor
  • Starting Flow (approx): 3 L/h
  • Minimum Flow Q1: 16 L/h
  • Transitional Flow Q2: 25 L/h
  • Maximum Flow Q3: 4 m³/h
  • Overload Flow Q4: 5 m³/h
  • Measuring Range Q3/Q1: 250
  • Max Pressure: MAP16
  • Max Working Pressure: 1 MPa
  • Temperature Class: T50
  • Ambient Humidity Range: 0 – 100% RH
  • Installation: Any position
  • Maximum Registration LCD: 999999.999m³
  • Calibration Min Reading: 0.0001 Litre
